Irons
Maltby TS1 IM Forged Iron Heads
Maltby TS1 IM Forged Iron Heads
Maltby TS1 IM Forged Iron Heads
Design Details
The Maltby TS1 IM (Injected Muscle) Forged Irons are a true billet forged 3 piece iron design that delivers performance and feel unlike any other muscle back iron head. This incredible playability and direct feedback comes from a combination of a very low and centered vertical center of gravity, modern loft specifications,
Design Details
The Maltby TS1 IM (Injected Muscle) Forged Irons are a true billet forged 3 piece iron design that delivers performance and feel unlike any other muscle back iron head. This incredible playability and direct feedback comes from a combination of a very low and centered vertical center of gravity, modern loft specifications, soft polymer material injected throughout the entire club head and a new 2.1mm Super Maraging steel face.
Revolutionary Construction
Forged using a Precision 5 Step Forging process for very precise parts requiring very little polishing to provide unparalleled specification tolerances. The TS1 IM head design features a 2.1mm Super Maraging steel forged face and a forged 1025C carbon steel body with an internal tungsten weight co-forged low and towards the toe inside the club head. The co-forged tungsten centers the vertical center of gravity location for a more stable head not typically found in a muscle back design. The pieces are then precision welded together leaving a void behind the entire club face that is injection filled with a proprietary polymer to enhance ball speeds and provide an exceptional feel on both center and off center hits.
Features:
- Model masters and tooling created using precision 3D CAD
- True Forged with a 1025C Carbon Steel body and MS300 Maraging Steel face, using the most advanced 5 step forging process available
- Hollow polymer injection filled 3 piece construction throughout the whole set
- A stunning Pearl Chrome finish reduces glare and offers excellent durability
- Unparalleled playability and feel for a true forged muscle back design
- Injected Polymer produces higher ball speeds with exceptional sound and feel
- Super Game Improvement (PF701+) design
- CNC milled face ensures face flatness for more consistency
- Multi-Groove technology places more CNC milled square grooves on the face for improved consistency, trajectory and spin
- Attractive and durable Pearl Nickel Chrome anti-glare finish protects the club head and enhances feel
- Reduced progressive offsets throughout the set as preferred by better players
- Progressive sole angle (bounce), modern tour leading edge grind and 4 way radius sole provides the optimum turf interaction from a variety of turf conditions.
- Modern lofts, combined with the optimal vertical cg locations, optimizes trajectory and distance.
- Universal hosel accepts both .370" parallel tip and .355" taper tip iron shafts.
- Recommended Ferrule - 74PI
Maltby TS3 Iron Head
Maltby TS1 IM Forged Iron Heads
Maltby TS1 IM Forged Iron Heads
The Maltby TS3 Forged irons feature a diminutive but modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position but provides Super Game Improvement playability.
True Forged using a Precision 5 Step Forging process for unparalleled specif
The Maltby TS3 Forged irons feature a diminutive but modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position but provides Super Game Improvement playability.
True Forged using a Precision 5 Step Forging process for unparalleled specification tolerances, the TS3 Forged head design features a forged 1025C carbon steel body with an internal tungsten weight co-forged low and towards the toe inside the club head. The co-forged tungsten centers the vertical center of gravity location for a more stable and playable head design.
To further enhance playability, the TS3 Forged irons feature a progressive cavity design that moves more mass low and towards the toe in the long irons and progresses to a more neutral position in the more lofted scoring irons and wedges.
TS3 Forged Iron Features:
- True Forged from 1025 Carbon Steel using a 5-Step Forging process creates a precision forged part for a more solid feel and extremely tight specification tolerances
- Tungsten weight Co-Forged into the toe of the club head
- Satin mirror nickel chrome finish
- Three unique progressive cavity designs in the set to position weight more towards the toe and lower in the long irons and centered and slightly higher in the short irons.
- Universal hosel design allows for both .355” taper tipped and .370” parallel tip iron shafts to be used
- Turf friendly radiused sole design with a relieved leading edge to improves turf interaction on any type of hitting surface
- Progressive sole widths range from .780” in the long irons to .800” in the wedges.
- Progressive offsets range from .115” in the long irons to .090” in the wedges
- Multi-Groove technology places more CNC milled square grooves on the face for improved consistency, trajectory and spin
- CNC Milled face ensures face flatness for improved consistency
- Modern lofts combined with optimal center of gravity locations optimizes ball flight trajectory and distance
- Recommended Ferrule - 74PI
- Conforms with the Rules of Golf
Maltby TS4 Forged Iron Heads
Maltby TS1 IM Forged Iron Heads
Maltby TE+ Forged Black DBM Iron Heads
The Maltby TS4 Forged Irons are true billet forged, using a Precision multi-step Forging process to produce very precise parts. Designed to be a pure players blade design that delivers performance and feel unlike any other muscle back iron head. This incredible playability and direct feedback comes from a detailed focus on the mass and d
The Maltby TS4 Forged Irons are true billet forged, using a Precision multi-step Forging process to produce very precise parts. Designed to be a pure players blade design that delivers performance and feel unlike any other muscle back iron head. This incredible playability and direct feedback comes from a detailed focus on the mass and dimensional characteristics of the design and creates an optimized center of gravity location in each head. Combined with the modern players loft specifications, the TS4 produces tour level trajectories, distance and feel.
The TS4 head design is a forged 1025C carbon steel and is co-forged with internal tungsten weight positioned low and towards the toe in the #3 thru the #8 iron to optimize the center of gravity location. The CNC milled face and “MG” (Multi-Groove) Technology ensures face flatness and places more grooves on the face for improved consistency. The sole is CNC milled to provide precise sole angle and radius specifications throughout the set. The TS4 features a modern tour leading edge grind and 4 way radius sole as well as graduated sole angles (bounce) to provide optimal turf interaction.
In the playing position, the TS4 irons present a traditional, classic players blade profile that will appeal to high level players as well as any level of player that prefers a traditional look at address. In addition to the look, the TS4 provides a high level of playability (Super Game Improvement performance), a hallmark of Maltby Design.
Features:
- True Forged from 1025C Carbon Steel using the most advanced 5 step forging process available.
- Co-Forged Internal tungsten weighting (#3 thru #8) provides precise vertical and horizontal cg locations to produce tour preferred trajectory and distance control.
- Unparalleled playability and feel for a true forged muscle back design
- Super Game Improvement (PF701+) design.
- CNC Milled leading edge and sole for precise bounce and sole radius' throughout the set
- CNC milled face ensures face flatness for more consistency
- CNC milled Multi-Groove technology places more CNC milled square grooves on the face for improved consistency, trajectory and spin
- Durable Pearl Nickel Chrome anti-glare finish protects the club head and enhances feel
- Minimal, progressive offsets and preferred top line widths provide a traditional look at address.
- Progressive sole angle (bounce), modern tour leading edge grind and 4 way radius sole provides the optimum turf interaction from a variety of turf conditions.
- Universal hosel accepts both .370" parallel tip and .355" taper tip iron shafts.
- Recommended Ferrule - 74PI for .370" shafts, 91TI for .355" shafts
- Conforms to the Rules of Golf
Maltby TE+ Forged Black DBM Iron Heads
Maltby TE+ Forged Pearl Chrome Iron Heads
Maltby TE+ Forged Black DBM Iron Heads
The Maltby TE+ V4 Forged irons are the 4th Generation of our best selling TE irons updated with modern head specifications and head profiles. The TE+ V4 Forged irons feature a modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position bu
The Maltby TE+ V4 Forged irons are the 4th Generation of our best selling TE irons updated with modern head specifications and head profiles. The TE+ V4 Forged irons feature a modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position but features an optimal vertical and horizontal center gravity location for an incredible 838 MPF points putting the club head into the high end of the Super Game Improvement category for incredible forgiveness.
True Forged using a Precision 5 Step Forging process for unparalleled specification tolerances, the TE+ V4 Forged head design features a forged 1025C carbon steel body with CNC milled face and scoring lines to ensure perfect face flatness and groove performance.
TE+ V4 Forged Iron Features:
- True Forged from 1025 Carbon Steel using a 5-Step Forging process creates a precision forged part that requires very little polishing for a more solid feel and extremely tight specification tolerances
- A stunning Pearl Chrome finish reduces glare and offers excellent durability
- Modern loft and lie specifications in a classic "players" cavity back design.
- Universal hosel design allows for both .355” taper tipped and .370” parallel tip iron shafts to be used
- Turf friendly radiused sole design with a relieved leading edge to improves turf interaction on any type of hitting surface
- A minimal and constant.100" offset throughout the entire set preferred by better players
- Multi-Groove technology places more CNC milled square grooves on the face for improved consistency, trajectory and spin
- CNC Milled face ensures face flatness for improved consistency
- Modern lofts combined with optimal center of gravity locations optimizes ball flight trajectory and distance
- Recommended Ferrule - 74PI
- Conforms with the Rules of Golf
Maltby TE+ Forged Pearl Chrome Iron Heads
Maltby TE+ Forged Pearl Chrome Iron Heads
Maltby TE+ Forged Pearl Chrome Iron Heads
The Maltby TE+ V4 Forged irons are the 4th Generation of our best selling TE irons updated with modern head specifications and head profiles. The TE+ V4 Forged irons feature a modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position bu
The Maltby TE+ V4 Forged irons are the 4th Generation of our best selling TE irons updated with modern head specifications and head profiles. The TE+ V4 Forged irons feature a modern profile preferred by a wide range of player types. Smooth lines and a moderate top line provide the looks of a "players" club head in the playing position but features an optimal vertical and horizontal center gravity location for an incredible 838 MPF points putting the club head into the high end of the Super Game Improvement category for incredible forgiveness.
True Forged using a Precision 5 Step Forging process for unparalleled specification tolerances, the TE+ V4 Forged head design features a forged 1025C carbon steel body with CNC milled face and scoring lines to ensure perfect face flatness and groove performance.
TE+ V4 Forged Iron Features:
- True Forged from 1025 Carbon Steel using a 5-Step Forging process creates a precision forged part that requires very little polishing for a more solid feel and extremely tight specification tolerances
- A stunning Pearl Chrome finish reduces glare and offers excellent durability
- Modern loft and lie specifications in a classic "players" cavity back design.
- Universal hosel design allows for both .355” taper tipped and .370” parallel tip iron shafts to be used
- Turf friendly radiused sole design with a relieved leading edge to improves turf interaction on any type of hitting surface
- A minimal and constant.100" offset throughout the entire set preferred by better players
- Multi-Groove technology places more CNC milled square grooves on the face for improved consistency, trajectory and spin
- CNC Milled face ensures face flatness for improved consistency
- Modern lofts combined with optimal center of gravity locations optimizes ball flight trajectory and distance
- Recommended Ferrule - 74PI
- Conforms with the Rules of Golf
Maltby KE4 MAX Iron Heads
Maltby TE+ Forged Pearl Chrome Iron Heads
Maltby TE+ Forged Pearl Chrome Iron Heads
The new Maltby KE4 MAX iron head main design concept was to surpass the overall playability of our best selling KE4 iron models from the past. Over a year in development, using the most advanced 3D modeling software, the new KE4 MAX irons have exceeded our design goals of increasing both forgiveness and distance propelling the KE4 MAX iro
The new Maltby KE4 MAX iron head main design concept was to surpass the overall playability of our best selling KE4 iron models from the past. Over a year in development, using the most advanced 3D modeling software, the new KE4 MAX irons have exceeded our design goals of increasing both forgiveness and distance propelling the KE4 MAX iron heads to the top of the modern "Game Improvement Distance Irons" category.
MAXimum Forgiveness
The KE4 MAX irons feature a deep undercut cavity with a interchangeable 8 gram weight screw positioned extremely low, as far towards the toe and rearward as possible. The positioning of the added toe mass moves the KE4 MAX iron's C-Dimension to an incredible 1.659". This lengthy C-Dimension measurement results in a horizontal center gravity location of .103" toe side of the geometric center of the clubface producing a very high MOI (Moment of Inertia) of 13.8912 oz-in² for MAXimum forgiveness on off center hits. The combination of the optimized MOI and C-Dimension increases the size of the club heads "sweet spot" to deliver longer and straighter golf shots when the ball is hit off center.
MAXimum Distance
The KE4 MAX iron lofts represent the strongest lofts available in the Maltby line of premium irons. However, strong lofts are not the only club head specification required to actually achieve longer golf shots. Golf shots hit on too low of a trajectory with little spin can result in a loss of distance and control. The KE4 MAX irons have an actual vertical center of gravity of .758" which is ideal for a wide range of swing speeds to produce the ideal golf ball trajectory and backspin needed for real world added distance and superb control.
MAXimum Adjustability
The KE4 MAX head weights can be customized to allow multiple shaft and length options to optimize the weight and feel for a wide variety of build options. The stock 8 gram weight of the KE4 MAX irons can be exchanged to increase or decrease the club head weight by +/-6 grams using the Maltby T-25 (MTW001) screw weights. The MTW001 screw weights are available in 2, 4, 6, 8, 10, 12 and 14 gram weight options.
Additional Features:
- Ultra Game Improvement design
- Precision cast from heat treated 17-4 Stainless Steel for durability and adjustability
- Attractive mirror polished finished
- Multi-Groove technology places more square grooves on the face for improved consistency, trajectory and spin
- Offsets progress from .180" in the #4 iron to .105" in the #9, PW and GW
- "High Toe/Low Heel" profile looks better in the playing position vs. traditional Ultra Game Improvement designs
- 4 way radiused sole design with progressive bounce angles and sole widths to provide optimal turf interaction from a variety of turf conditions.
- Recommended Ferrule - 60PI
- Conforms with the Rules of Golf
Maltby STi2 Irons Heads
Maltby STi2 Irons Heads
Maltby STi2 Irons Heads
The STi2 irons fall into the Super Game Improvement Design category and provide enhanced playability for a wide range of golfers. STi2 irons offer a pleasing and confidence building mid-sized profile featuring an undercut cavity to produce a low (.729") and deep center of gravity location for optimal distance and control. A four way radiu
The STi2 irons fall into the Super Game Improvement Design category and provide enhanced playability for a wide range of golfers. STi2 irons offer a pleasing and confidence building mid-sized profile featuring an undercut cavity to produce a low (.729") and deep center of gravity location for optimal distance and control. A four way radius sole design allows for great turf interaction in any type of course condition.
Features:
- Precision cast from soft 431 Stainless Steel for a soft "forged" like feel and easy adjustability
- Variable Face Thickness (VFT) Design increases ball speeds on off center impacts
- Progressive offset enhances the playability of each club in the set. Longer irons have increased offset (.138") to help square the clubface at impact progressing down to .098" offset in the higher lofted scoring clubs for improved alignment
- Progressive Undercut Cavity Design places more weight to the rear and perimeter of the club head for high launching shots and increased directional control
- A Silica Gel Vibration reducing insert inside the undercut cavity of the #4 thru #7 irons absorbs unwanted shock on off center hits and produces a confidence adding, extremely solid sound and feel at impact
- Optimal bounce angles and sole widths help reduce fat shots without negatively affecting playability
- "MG" (Multi Groove) Technology places more grooves on the face for improved consistency in both trajectory and spin.
- Available in RH and LH options.
- Recommended ferrule - 54PI
